| # -*- coding: utf-8 -*-
"""ML2022Spring - HW1.ipynb
Automatically generated by Colaboratory.
Original file is located at
https://colab.research.google.com/drive/1FTcG6CE-HILnvFztEFKdauMlPKfQvm5Z
# **Homework 1: COVID-19 Cases Prediction (Regression)**
Objectives:
* Solve a regression problem with deep neural networks (DNN).
* Understand basic DNN training tips.
* Familiarize yourself with PyTorch.
If you have any questions, please contact the TAs via TA hours, NTU COOL, or email to mlta-2022-spring@googlegroups.com
# Download data
If the Google Drive links below do not work, you can download data from [Kaggle](https://www.kaggle.com/t/a3ebd5b5542f0f55e828d4f00de8e59a), and upload data manually to the workspace.
!gdown --id '1kLSW_-cW2Huj7bh84YTdimGBOJaODiOS' --output covid.train.csv
!gdown --id '1iiI5qROrAhZn-o4FPqsE97bMzDEFvIdg' --output covid.test.csv
"""
"""# Import packages"""
# Numerical Operations
# Reading/Writing Data
# For Progress Bar
# Pytorch
# For plotting learning curve
"""# Some Utility Functions
You do not need to modify this part.
"""
from sklearn.feature_selection import SelectKBest, f_regression
import math
import numpy as np
import pandas as pd
import os
import csv
from tqdm import tqdm
import torch
import torch.nn as nn
from torch.utils.data import Dataset, DataLoader, random_split
from torch.utils.tensorboard import SummaryWriter
def same_seed(seed):
'''Fixes random number generator seeds for reproducibility.'''
torch.backends.cudnn.deterministic = True
torch.backends.cudnn.benchmark = False
np.random.seed(seed)
torch.manual_seed(seed)
if torch.cuda.is_available():
torch.cuda.manual_seed_all(seed)
def train_valid_split(data_set, valid_ratio, seed):
'''Split provided training data into training set and validation set'''
valid_set_size = int(valid_ratio * len(data_set))
train_set_size = len(data_set) - valid_set_size
train_set, valid_set = random_split(data_set, [
train_set_size, valid_set_size], generator=torch.Generator().manual_seed(seed))
return np.array(train_set), np.array(valid_set)
def predict(test_loader, model, device):
model.eval() # Set your model to evaluation mode.
preds = []
for x in tqdm(test_loader):
x = x.to(device)
with torch.no_grad():
pred = model(x)
preds.append(pred.detach().cpu())
preds = torch.cat(preds, dim=0).numpy()
return preds
"""# Dataset"""
class COVID19Dataset(Dataset):
'''
x: Features.
y: Targets, if none, do prediction.
'''
def __init__(self, x, y=None):
if y is None:
self.y = y
else:
self.y = torch.FloatTensor(y)
self.x = torch.FloatTensor(x)
def __getitem__(self, idx):
if self.y is None:
return self.x[idx]
else:
return self.x[idx], self.y[idx]
def __len__(self):
return len(self.x)
"""# Neural Network Model
Try out different model architectures by modifying the class below.
"""
class My_Model(nn.Module):
def __init__(self, input_dim):
super(My_Model, self).__init__()
# TODO: modify model's structure, be aware of dimensions.
self.layers = nn.Sequential(
nn.Linear(input_dim, 192),
nn.ReLU(),
nn.Dropout(0.2),
nn.Linear(192, 1),
)
def forward(self, x):
x = self.layers(x)
x = x.squeeze(1) # (B, 1) -> (B)
return x
"""# Feature Selection
Choose features you deem useful by modifying the function below.
"""
def split_data(data):
p = np.array([0, 1, 2, 3, 15, 16, 17, 18, 19, 31, 32, 33, 34, 35])
X = [data[:, p + i * 16 + 38] for i in range(3)]
Y = [data[:, (i+3)*16 + 38 - 1] for i in range(3)]
X = np.vstack(X)
Y = np.hstack(Y)
return X, Y
def select_feat(train_data, valid_data, test_data, select_all=True):
'''Selects useful features to perform regression'''
raw_x_train, y_train = split_data(train_data)
raw_x_valid, y_valid = split_data(valid_data)
raw_x_test = test_data[:, np.array(
[0, 1, 2, 3, 15, 16, 17, 18, 19, 31, 32, 33, 34, 35]) + 38 + 16 * 2]
return raw_x_train, raw_x_valid, raw_x_test, y_train, y_valid
"""# Training Loop"""
def trainer(train_loader, valid_loader, model, config, device):
# Define your loss function, do not modify this.
criterion = nn.MSELoss(reduction='mean')
# Define your optimization algorithm.
# TODO: Please check https://pytorch.org/docs/stable/optim.html to get more available algorithms.
# TODO: L2 regularization (optimizer(weight decay...) or implement by your self).
# optimizer = torch.optim.SGD(model.parameters(), lr=config['learning_rate'], momentum=0.9, weight_decay=1e-3)
optimizer = torch.optim.Adam(model.parameters(), weight_decay=5e-5)
scheduler = torch.optim.lr_scheduler.CosineAnnealingWarmRestarts(optimizer,
T_0=2, T_mult=3, eta_min=0)
writer = SummaryWriter() # Writer of tensoboard.
if not os.path.isdir('./models'):
os.mkdir('./models') # Create directory of saving models.
n_epochs, best_loss, step, early_stop_count = config['n_epochs'], math.inf, 0, 0
for epoch in range(n_epochs):
model.train() # Set your model to train mode.
loss_record = []
# tqdm is a package to visualize your training progress.
train_pbar = tqdm(train_loader, position=0, leave=True)
for x, y in train_pbar:
optimizer.zero_grad() # Set gradient to zero.
x, y = x.to(device), y.to(device) # Move your data to device.
pred = model(x)
loss = criterion(pred, y)
# Compute gradient(backpropagation).
loss.backward()
optimizer.step() # Update parameters.
step += 1
loss_record.append(loss.detach().item())
# Display current epoch number and loss on tqdm progress bar.
train_pbar.set_description(f'Epoch [{epoch+1}/{n_epochs}]')
train_pbar.set_postfix({'loss': loss.detach().item()})
scheduler.step()
mean_train_loss = sum(loss_record)/len(loss_record)
writer.add_scalar('Loss/train', mean_train_loss, step)
model.eval() # Set your model to evaluation mode.
loss_record = []
for x, y in valid_loader:
x, y = x.to(device), y.to(device)
with torch.no_grad():
pred = model(x)
loss = criterion(pred, y)
loss_record.append(loss.item())
mean_valid_loss = sum(loss_record)/len(loss_record)
print(
f'Epoch [{epoch+1}/{n_epochs}]: Train loss: {mean_train_loss:.4f}, Valid loss: {mean_valid_loss:.4f}')
writer.add_scalar('Loss/valid', mean_valid_loss, step)
if mean_valid_loss < best_loss:
best_loss = mean_valid_loss
# Save your best model
torch.save(model.state_dict(), config['save_path'])
print('Saving model with loss {:.3f}...'.format(best_loss))
early_stop_count = 0
else:
early_stop_count += 1
if early_stop_count >= config['early_stop']:
print('\nModel is not improving, so we halt the training session.')
return
"""# Configurations
`config` contains hyper-parameters for training and the path to save your model.
"""
device = 'cuda' if torch.cuda.is_available() else 'cpu'
config = {
'seed': 19260817, # Your seed number, you can pick your lucky number. :)
'select_all': False, # Whether to use all features.
'valid_ratio': 0.2, # validation_size = train_size * valid_ratio
'n_epochs': 5000, # Number of epochs.
'batch_size': 192,
'learning_rate': 1e-5,
# If model has not improved for this many consecutive epochs, stop training.
'early_stop': 500,
'save_path': './models/model.ckpt' # Your model will be saved here.
}
"""# Dataloader
Read data from files and set up training, validation, and testing sets. You do not need to modify this part.
"""
# Set seed for reproducibility
same_seed(config['seed'])
# train_data size: 2699 x 118 (id + 37 states + 16 features x 5 days)
# test_data size: 1078 x 117 (without last day's positive rate)
train_data, test_data = pd.read_csv(
'./covid.train.csv').values, pd.read_csv('./covid.test.csv').values
train_data, valid_data = train_valid_split(
train_data, config['valid_ratio'], config['seed'])
# Print out the data size.
print(f"""train_data size: {train_data.shape}
valid_data size: {valid_data.shape}
test_data size: {test_data.shape}""")
# Select features
x_train, x_valid, x_test, y_train, y_valid = select_feat(
train_data, valid_data, test_data, config['select_all'])
# Print out the number of features.
print(f'number of features: {x_train.shape[1]}')
train_dataset, valid_dataset, test_dataset = COVID19Dataset(x_train, y_train), \
COVID19Dataset(x_valid, y_valid), \
COVID19Dataset(x_test)
# Pytorch data loader loads pytorch dataset into batches.
train_loader = DataLoader(
train_dataset, batch_size=config['batch_size'], shuffle=True, pin_memory=True)
valid_loader = DataLoader(
valid_dataset, batch_size=config['batch_size'], shuffle=True, pin_memory=True)
test_loader = DataLoader(
test_dataset, batch_size=config['batch_size'], shuffle=False, pin_memory=True)
"""# Start training!"""
# put your model and data on the same computation device.
model = My_Model(input_dim=x_train.shape[1]).to(device)
trainer(train_loader, valid_loader, model, config, device)
"""# Plot learning curves with `tensorboard` (optional)
`tensorboard` is a tool that allows you to visualize your training progress.
If this block does not display your learning curve, please wait for few minutes, and re-run this block. It might take some time to load your logging information.
"""
# Commented out IPython magic to ensure Python compatibility.
# %reload_ext tensorboard
# %tensorboard --logdir=./runs/
"""# Testing
The predictions of your model on testing set will be stored at `pred.csv`.
"""
def save_pred(preds, file):
''' Save predictions to specified file '''
with open(file, 'w') as fp:
writer = csv.writer(fp)
writer.writerow(['id', 'tested_positive'])
for i, p in enumerate(preds):
writer.writerow([i, p])
model = My_Model(input_dim=x_train.shape[1]).to(device)
model.load_state_dict(torch.load(config['save_path']))
preds = predict(test_loader, model, device)
save_pred(preds, 'pred.csv')
"""# Reference
This notebook uses code written by Heng-Jui Chang @ NTUEE (https://github.com/ga642381/ML2021-Spring/blob/main/HW01/HW01.ipynb)
"""
|
